Syndeo by Tagra | Delayed Timer PIR Motion | Wired LED Sensor | IP20

Technical Specifications:

• Voltage: 12V and 24V
• Standby Power: < 0.3W
• Sensor Range: 0-3000mm
• Material: Plastic
• Colour: Silver
• Cable Length: 2000mm
• IP Rating: IP20
• Installation: Recessed (12mm Cut Out) or Surface Mounted (Mouting Bracket Included)
• Dimensions (mm): L 40.3 x W 11.8
• Guarantee: 3 Years
• Certification: RoHS, CE

Lighting Control Made Simple

This PIR motion sensor is perfect for long range motion detection, with a detection angle of 90º it works by either turning the lights on or off when motion is detected from a distance of Up to 3000mm.

When triggered, the lights will remain on for 15 minuites whilst no motion is detected.

Can with be recessed into a 12mm diameter hole with a depth of 60mm or surface mounted using the mounting bracket included in the package.

Designed to plug directly into the master control port of a 12V or 24V Plug and Play Syndeo Driver to control an entire lighting system. Comes equipped with a detachable cable for ease of install, fully plug and play and no need for soldering, saving you time and cost on your project.

*Please Note: Compatible with Syndeo Drivers and Components only and not Ready to Connect Components or Drivers.

Mounting bracket included

All products should be installed by a technically competent person in accordance with BS7671 and all other local regulations.
