Mean Well | XLG | 100W | 1750-2780mA | Constant Power | 3 in 1 Dimmable LED Driver | IP67

These are constant power LED drivers, not constant voltage. They automatically adjust voltage and current to suit the LED load and are intended for compatible LED modules. Not suitable for standard constant voltage LED strip lighting.

Specification

• 100W Constant Power LED Driver
• Output Current Range: 1750–2780mA
• Constant Power LED driver with constant current operating range
• 3-in-1 dimming: 0–10V / PWM signal / resistance
• Input voltage: 100–305VAC
• IP67 rated for indoor & outdoor applications
• Protections: short circuit, overload, over-voltage, over-temperature
• Fanless design with free air convection cooling
• Efficiency: up to 92%
• Power factor: >0.95
• Standby power consumption: <0.5W
• Lifetime: >50,000 hours
• 5 year warranty

The Mean Well XLG-100-H-AB is a high-performance 100W constant power LED driver, designed for demanding commercial and outdoor lighting applications. Operating in constant power mode, it automatically adjusts output voltage and current to maintain stable performance across a wide operating range.

Built for reliability, this driver features a robust metal housing with IP67 protection, making it suitable for both indoor and outdoor installations. Adjustable output current via internal potentiometer plus 3 in 1 dimming control (0–10V, PWM, and resistance), it offers flexible control without the need for complex digital systems.

Engineered for professional use, the XLG-100-H-AB delivers consistent output with high efficiency and long operational life. The constant power design allows flexible compatibility with a wide range of LED configurations, particularly where current requirements may vary.

With a wide 100–305VAC input range, built-in surge protection, and full electronic protections, this driver is ideal for architectural, floodlighting, and industrial lighting applications. The fanless design ensures silent operation and minimal maintenance over time.
