Syndeo by Tagra | Short Range PIR Hand Motion | Wired LED Sensor | IP20
SYN-MOTSWITCH
£13.43 Inc. VAT
Key Features
- Input voltage (Min/Max): 12 V – 24 V
- Colour control type: Single colour
- Mounting Type: Surface Mounted or Recessed
- IP Rating: 20
- Warranty: 3 Years
Pay by card, American Express, PayPal, Apple Pay or Google Pay
Delivery & Returns
- Free UK DeliveryOrders over £75
- Next Day DeliveryFrom £8.95
- Returns14 Day Policy
Product Overview
Technical Specifications:
- Voltage: 12V and 24V
- Standby Power: < 0.3W
- Sensor Range: 0-50mm
- Material: Plastic
- Colour: Silver
- Cable Length: 2000mm
- IP Rating: IP20
- Installation: Recessed (12mm Cut Out) or Surface Mounted
- Dimensions (mm): L 40.3 x W 11.8
- Guarantee: 3 Years
- Certification: RoHS, CE
Lighting Control Made Simple
This hand movement switch is perfect for short range motion detection, with a detection angle of 20º it works by turning the lights on or off when motion is detected from a distance of Up to 50mm.
Can with be recessed into a 12mm diameter hole with a depth of 50mm or surface mounted using the mounting bracket included in the package.
Designed to plug directly into the master control port of a 12V or 24V Plug and Play Syndeo Driver to control an entire lighting system. Comes equipped with a detachable cable for ease of install, fully plug and play and no need for soldering, saving you time and cost on your project.
*Please Note: Compatible with Syndeo Drivers and Components only and not ready to connect Components or Drivers.
All products should be installed by a technically competent person in accordance with BS7671 and all other local regulations.
Product Specification
| Control Distance No Obstruction (m) | 0.05 |
| Application Environment | Indoor |
| Body Material | Plastic |
| Ingress Protection (IP) | 20 |
| Interior or Exterior Use | Interior |
| Input Current Type (A) | DC |
| Input Voltage Min. - Max (V) | 12-24V |
| Body Colour | Silver |
| Product Weight (g) | 72 |
| Battery Included | No |
| Items/Sets Per Pack | 1 |
| Brand | SYNDEO |
| Warranty (Years) | 3 |
| Product Height (mm) | 300 |
| Depth (mm) | 225 |
| Width (mm) | 290 |
| Dimensions LxWxH (mm) | 225x290x300 |
| Family Name | Syndeo Wired |
| Mounting Type | Surface Mounted,Recessed |
| Cable Length (mm) | 2000 |
Technical Documents
