Tagra | Low Voltage LED Cable | 2 Core | 5A | Silicone | Round | 20AWG | 0.5mm²
SILCBL-2C
From £18.00 Inc. VAT
Key Features
- Current (max rated): 5 A
- Input cross-section of conductors for terminals: 0.5 mm²
- Input voltage (Min/Max): 12V–60V
- Body colour: Black; White
- Cable shape: Round
- Cable sheath material: Silicone
- Cable conductor material: Copper
- Cable length: 10 m; 50 m; 100 m
- Warranty: 3 Years; 3.0 Years
Pay by card, American Express, PayPal, Apple Pay or Google Pay
Delivery & Returns
- Free UK DeliveryOrders over £75
- Next Day DeliveryFrom £8.95
- Returns14 Day Policy
Product Overview
Technical Specifications:
- Cores: 2x (20/0.18mm) manufactured with Silicone insulation
- Conductor Cross Section: 0.5mm²
- Current Capacity: 5.0A per core
- Operating Temperature Range: -60°C to +200°C
- Flame Retardant: FT-2
- Minimum Bend Radius: 30mm
- Voltage Rating: 60V
- Cable Sheath: High-grade Silicone demonstrating excellent flexibility and resistance to extreme temperatures
- Cable End: Tinned Copper for superior conductivity
- Cable Gauge: 20 AWG
- Lengths Available: Sold in 10m, 50m, and 100m lengths
This silicone-insulated, precision-engineered 2-core cable has been manufactured to the highest standards for use with various LED lighting systems or other low-voltage applications. Its high flexibility and small bend radius allow for easy installation in confined spaces or areas requiring tight bends. It’s also flame-retardant, making it a safe and durable choice for a wide range of environments. This cable can handle up to 5 amps per core, making it both versatile and reliable for various electrical systems.
Product Specification
| Warranty (Years) | 3 |
| Voltage Max. Rated (V) | 60 |
| Width (mm) | 5 |
| Items/Sets Per Pack | 1 |
| Brand | Tagra |
| Family Name | Low Voltage Cable |
| Ingress Protection (IP) | 20 |
| Body Material | Silicone |
