Tagra | Build LED Neon Flex | Horizontal 16.5 | 16.5x16.5mm | RGB | 24V | IP68 | 13Wp/m | Custom
NEON-FAC-HB-165165-24V-RGB
Key Features
- Up to 195 Lumens per metre
- IP68
- 16.5mm x 16.5mm
- 5 Year Warranty
- 120° Illumination
- Horizontal Bending
- Available as Sold by the Metre
- RGB Colour Changing
- Anti-Wicking Ferrule Features
Contact Us
Please complete the details of your enquiry below and we'll be in touch shortly.
Your data will be held in accordance with our privacy policy which can be found here.
Product Overview
Introducing Our 16.5x16.5 Horizontal Bend LED Neon Flex – 24V RGB
Perfect for architectural and façade lighting, our 16.5x16.5 Horizontal Bend LED Neon Flex is a professional-grade RGB lighting solution designed for vibrant colour control and long-lasting performance. Constructed from durable silicone and engineered for horizontal flexibility, this product supports a wide variety of creative lighting configurations.
Whether you’re looking to bring vivid colour to a commercial project, accent building outlines, or deliver seamless lighting across curved structures, our 16.5x16.5 Horizontal Bend LED Neon Flex provides consistent, high-quality illumination. Available in RGB and supplied as standard in 24V.
Key Features
- RGB Colour Changing
- IP68
- 16.5mm x 16.5mm
- 5 Year Warranty
- 120° Beam Angle
- Horizontal Bending
- Available as Sold by the Metre
- Cut Points Every 83.3mm
Installation
This IP68-rated Neon Flex is designed for outdoor and architectural use. For optimal performance and secure fitting, we recommend using suitable mounting accessories. The product can be cut to size on-site to suit your design layout.
Required Products
To operate this product effectively, you’ll need the following:
- A compatible 24V RGB LED Driver
Product Specification
| Warranty (Years) | 5 |
| Dimmable | Yes |
| Current Max. Rated (A) | 5.41 |
| Max. Run Length (m) | 10 |
| Anti-Yellowing | Yes |
| Application Environment | Facades |
| Body Material | Silicone |
| Ingress Protection (IP) | 68 |
| Interior or Exterior Use | Interior or Exterior |
| Saltwater Resistant | Yes |
| Solvent Resistant | Yes |
| UV Resistant | Yes |
| Input Voltage Min. - Max (V) | 24-24V |
| Body Colour | White |
| Cable Weight (AWG) | 20 |
| Chip Type | 5050 |
| Copper Foil Weight (oz) | 4 |
| Cut Points (mm) | 83.33 |
| Entry Cable Direction | Rear, Side, Bottom |
| LED Module Replaceable | No |
| LED Pitch (mm) | 13.88 |
| LEDs Per Metre (LEDs/m) | 72 |
| Min. Bend Radius (mm) | 75 |
| Product Height (mm) | 17 |
| Product Weight (g) | 460 |
| Width (mm) | 17 |
| Constant Voltage / Constant Current | CV |
| Beam Angle (°) | 120 |
| R9 CRI Value | 60 |
| SDCM | 3 |
| Wavelength Blue Max. (nm) | 475 |
| Wavelength Blue Min. (nm) | 465 |
| Wavelength Green Max. (nm) | 530 |
| Wavelength Green Min. (nm) | 520 |
| Wavelength Red Max. (nm) | 630 |
| Wavelength Red Min. (nm) | 620 |
| Electrical Safety Class | III |
| Operating Temperature Min. - Max. (°C) | -40℃ to 55℃ |
| Dimensions LxWxH (mm) | 1000x17x17 |
| Brand | Tagra |
| Family Name | Build Series |
| Certification | EMC - 2014/30/EU |
| Bend Direction | Horizontal |
| Cable Sheath Material | Silicone |
| CRI | 90 |
