Tagra | Decor LED Neon Flex | Dual Circ 40 | 40x40mm | RGB | 24V | IP65 | 16.5Wp/m | Custom
NEON36040-1M-RGB
Key Features
- Product Dimensions (mm): W40xH40
- Bend direction: Dual
- Lm/m (up to): 445 Lm/m
- Lm/W (up to): 30 Lm/W
- Run length (max): 5 m
- Available Colours: RGB
- Warranty: 3 Years
Product Overview
Introducing Our 40x40 RGB Circular LED Neon Flex
Ideal for a variety of indoor installations, our 40x40 RGB Circular LED Neon Flex is constructed from high-quality silicone and boasts exceptional flexibility & durability. Whether you're looking to enhance architectural features, create eye-catching retail displays, or elevate your residential projects, our Professional 40x40 RGB Circular LED Neon Flex produces 360° of spotless illumination, creating a unique visual impact.
From architectural elements to decorative lighting, this LED neon flex is engineered to offer unparalleled flexibility, allowing for effortless bending and shaping to accommodate even the most intricate designs and layouts. Designed to meet the demands of lighting designers, electricians, and contractors, it elevates any space with a seamless, professional-grade lighting solution.
Key Features
With dual bend flexibility, this LED neon has a minimum bend diameter of 480mm. It offers uniform, shadow-free illumination across all colours and as is available in sold by the metre lengths. The durable, anti-yellowing silicone material is rated at IP65 making it suitable for indoor installations. A 360° beam angle delivers smooth uninterupted light, and pre-soldered tails enable quick setup. Comes with a 3 year warranty as standard.
Specifications
- Voltage: 24V DC
- Typ. Power: 14.4W/m
- LEDs per metre: 280 LEDs
- Cut Points: 50mm
- Beam Angle: 360°
- Dimensions: W40mm x H40mm
- Lumens per metre: Up to 445lm
- Warranty: 3 Years
- IP Rating: IP65 (suitable for indoor use)
Installation
The IP65-rated LED Neon Flex is designed for indoor applications, featuring a durable rear-entry cable for easy installation. For optimal performance and secure placement, we recommend using mounting tracks.
Required Products
To operate this product effectively, you’ll need the following:
- A compatible 24V LED Driver
- A compatible RGB Controller
Product Specification
Warranty (Years) | 3 |
Control Signal - Input | PWM |
Dimmable | Yes |
Current Max. Rated (A) | 0.66 |
Max. Run Length (m) | 5 |
Body Material | Silicone |
Ingress Protection (IP) | 65 |
Interior or Exterior Use | Indoor |
Saltwater Resistant | Yes |
Solvent Resistant | Yes |
UV Resistant | Yes |
Input Voltage Min. - Max (V) | 24-24V |
Body Colour | White |
Cut Points (mm) | 50 |
LEDs Per Metre (LEDs/m) | 280 |
Min. Bend Radius (mm) | 240 |
Product Height (mm) | 40 |
Depth (mm) | 1000 |
Width (mm) | 40 |
Constant Voltage / Constant Current | CV |
Beam Angle (°) | 360 |
Lumens Per Metre (Lm/m) | 445 |
Lumens Per Watt (Lm/W) | 30 |
SDCM | 2 |
Electrical Safety Class | III |
Operating Temperature Min. - Max. (°C) | -25℃ to 55℃ |
Dimensions LxWxH (mm) | 1000x40x40 |
Brand | Tagra |
Certification | EMC - 2014/30/EU |
Bend Direction | Dual |
Cable Sheath Material | PVC |
Family Name | D?cor Series |
CRI | 90 |
Entry Cable Direction | Rear, Side, Bottom |
Technical Documents
