Tagra | 12V | 30W | Constant Voltage | TRIAC Dimmable LED Driver | IP20
TAGTRIAC12V30WB
£23.40 Inc. VAT
Key Features
- Dimming Type: TRIAC
- Dimming Range: 20% - 90%
- CV / CC: CV
- Input Voltage: 220V - 240V
- Output Voltage: 12V
- Rated output current: 2.5A
- IP Rating: 20
- Body Material: Plastic
- Product Dimensions (mm): L158xW46xH18
| Quantity | Price |
|---|---|
| 4 - 14 | £21.76 (save £1.64) |
| 15 + | £18.72 (save £4.68) |
Pay by card, American Express, PayPal, Apple Pay or Google Pay
Delivery & Returns
- Free UK DeliveryOrders over £75
- Next Day DeliveryFrom £8.95
- Returns14 Day Policy
Product Overview
Specifications:
- Output Voltage: 12V DC
- Output Current: 2.5A
- Rated Power: 30W
- Efficiency: 85%
- Power Factor: 0.9
- Dimmable: Yes
- Dimming Range: 10-100%
- Water Resistance: IP20
- Dimensions (mm): 158L x 45.8W x 18.3H
- Warranty: 5 Years
Information:
Introducing our Professional TRIAC Dimmable range of LED Power Supplies. This power supply support leading edge (TRIAC) and trailing edge (ELV) dimmers and can be used to achieve smooth dimming effects. This product is designed for demanding installations and is manufactured from high quality materials and components to produce a reliable and efficient LED Driver. Featuring built-in protection and protective terminal covers, it's the prefect solution for any installation.
Manufactured from high quality materials and components and comes with a 5 year warranty as standard.
Installation:
Available in IP20 making it suitable for indoor installation. Designed to be connected to a mains power supply (220-240V AC). Can be mounted to a surface using the fixing points located on the product casing. We recommend this product be installed by a qualified electrician.
Required Products:
The list of products below are required in order to properly operate this product:
- 220-240V AC Mains Power Supply
- 12V LED Strip Light
- 12V Compatible LED Dimmer
Product Specification
| Warranty (Years) | 5 |
| Control Signal - Input | TRIAC |
| Dimmable | Yes |
| Dimming Type | TRIAC |
| Rated Life (Hours) | 30000 |
| Power Factor (A) | 0.9 |
| Application Environment | Domestic |
| Body Material | Plastic |
| Ingress Protection (IP) | 20 |
| Interior or Exterior Use | Interior |
| Storage Humidity Max. (°C) | 95 |
| Working Humidity Max. (°C) | 90 |
| Input Cross-Section of Conductors for Terminals (mm²) | 0.75 |
| Input Current Type (A) | AC |
| Input Terminal / Connector Type | Screw terminal |
| Number of Input Terminals | 2 |
| Input Frequency Min. - Max. (Hz) | 50-60Hz |
| Input Voltage Min. - Max (V) | 220-240V |
| Body Colour | White |
| DIN Rail Compatible | No |
| Product Height (mm) | 18 |
| Depth (mm) | 158 |
| Product Weight (g) | 520 |
| Width (mm) | 46 |
| Constant Voltage / Constant Current | CV |
| Load Min. (W) | 0 |
| Number of Output Terminals | 2 |
| Output Current Max. (A) | 2.5 |
| Output Current Type | DC |
| Output Terminal / Connector Type | Screw terminal |
| Output Voltage Min. - Max. (V) | 12-12V |
| Power Cord Included | No |
| Electrical Safety Class | II |
| Over Current Protection | Yes |
| Over Temperature Protection | No |
| Over Voltage Protection | Yes |
| Short Circuit Protection | Yes |
| Dimming Range Min. - Max (%) | 20-90% |
| Operating Temperature Min. - Max. (°C) | -20℃ to 45℃ |
| Dimensions LxWxH (mm) | 158x46x18 |
| Brand | Tagra |
| Certification | EMC - 2014/30/EU |
| Wattage (W) | 30 |
| Family Name | Tagra Triac 12V |
| Max. Output Current Per Channel (A) | 2.5 |
| Mounting Type | Surface Mounted |
