Tagra | DMX & RF 2.4GHz | 12-48V | LED Controller | 4 Channel | Single Colour - RGB+W | IP20

Specifications:

• Input Signal: Wi-Fi, RF 2.4GHz
• DMX Connection: Screw Terminal, RJ45
• Input Voltage: 12–48V DC
• Input Current: Max. 32.5A
• Output Voltage: 4 x (12-48) VDC
• Output Current: 4 x 8A @ 12/24V | 4 x 6A @ 36/48V
• Output Power: 4 x 96W @ 12V | 4 x 192W @ 24V | 4 x 216W @ 36V | 4 x 288W @ 48V
• Output Type: Constant Voltage
• Dimensions(mm): 120L x 43W x 27H
• Warranty: 5 Years

Information

Multi-Channel DMX Control. Master–Slave Configuration. Smart Wireless Integration.

Featuring a 4 channel constant voltage output, this LED Controller is designed for controlling Single Colour, CCT Tunable White, RGB and RGBW strip lights. It supports DMX512, RF and Wi-Fi functions, allowing reliable control and easy configuration within compatible systems.

This DMX LED Controller includes built-in Wi-Fi connectivity and Tuya Smart app integration, lighting can be controlled remotely via smartphone, allowing adjustment of brightness, colour, scenes, timers and dynamic effects. Voice control compatibility with Amazon Alexa and Google Assistant adds further convenience, making it ideal for both residential and commercial smart lighting installations.

Choose between 8-bit (256 levels) or 16-bit (65,536 levels) dimming resolution, along with adjustable dimming curves including linear adjustments. The controller features both master and slave modes via DIP switch configuration, allowing multiple units to be synchronised for larger installations. Master and slave communication adopts an RJ45 interface and complies with the DMX512 standard protocol, with the slave also supporting use with a 4-channel DMX512 decoder with 16-bit decoding.

Built using high quality components, this unit includes built-in reverse polarity and is supplied with a 5 year warranty as standard.

Required Products:

The list of products below are required to properly operate this product:

• 12V / 24V / 48V LED Power Supply

• Compatible LED Strip Single Colour, CCT Tunable White, RGB & RGBW
